IMBH62. HYDRAULIC CONTROL FITTING
NO. PART NO. DESCRIPTION Q'TY I.C. SERIAL OR DATE
1 40294009 VALVE,WALVOIL SD6/6 1
2 40230928 BUCKET CYLINDER ASSEMBLY 1
3 40230934 DIPPERSTICK CYLINDER ASSEMBLY 1
4 40230937 BOOM CYLINDER ASSEMBLY 1
5 40230918 SWING CYLINDER ASSEMBLY 2
6 40230910 STABILIZER CYLINDER ASSEMBLY-LH 1
7 40230913 STABILIZER CYLINDER ASSEMBLY-RH 1
8 40230948 ADAPTER LONG,1/2-20UNF×3/4-16UNF,O-RING 4
9 40230949 ORIFICE LONG,1/2-20UNF×3/4-16UNF,O-RING 2
10 40230947 ADAPTER SHORT,1/2-20UNF×3/4-16UNF,O-RING 4
11 40230950 ORIFICE SHORT,1/2-20UNF×3/4-16UNF,O-RING 2
12 40294010 ADAPTER ELBOW,7/8-14UNF,HOSE×7/8-14UNF,O-RING 90° 2
13 40230966 NIPPLE,PT1/2×7/8-14UNF,HOSE 2
14 40230971 DUST-CAP,1/2" BLACK FEMALE 2
15 40230967 QUICK COUPLER,PT1/2 MALE 2
16 40230953 NIPPLE,PF1/4,O-RING×1/2-20UNF 14
17 40230962 NIPPLE,9/16-18UNF×1/2-20UNF 2
18 40230943 O-RING, AS568 #908,AS568 #908 12
19 40230701 O-RING,1BP11 16
20 40230944 O-RING, AS568 #910,AS568 #910 2
21 40231109 NIPPLE KIT,1/2-20UNF×1/2-20UNF,NUT 2
22 40294008 PIPE ASS'Y 2
23 40230963 ADAPTER,PF1/4×9/16-18UNF 2
24 40231038 HOSE ASS'Y,1/4×4×4×550L 2
40343511 HOSE ASS'Y,904(1/2-20UNF)-4(1/2-20UNF) 550L(1/4) 2 2016.03.15~
25 40231039 HOSE ASS'Y,1/4×904×4×950L 2
40343512 HOSE ASS'Y,904(1/2-20UNF)-4(1/2-20UNF) 950L(1/4) 2 2016.03.15~
26 40231040 HOSE ASS'Y,1/4×904×4×1300L 4
40343513 HOSE ASS'Y,904(1/2-20UNF)-4(1/2-20UNF) 1300L(1/4) 4 2016.03.15~
27 40231110 HOSE ASS'Y,1/4×904×4×2500L 2
40343518 HOSE ASS'Y,904(1/2-20UNF)-4(1/2-20UNF) 2500L(1/4) 2 2016.03.15~
28 40231111 HOSE ASS'Y,1/4×904×4×2530L 2
40343519 HOSE ASS'Y,904(1/2-20UNF)-4(1/2-20UNF) 2530L(1/4) 2 2016.05.15~
29 40231112 HOSE ASS'Y,1/4×4×4G/W×900L 2
30 40294011 HOSE ASS'Y,904(1/2-20UNF)-4(1/2-20UNF) 1890L(1/4) 2
40343514 HOSE ASS'Y,904(1/2-20UNF)-4(1/2-20UNF) 1890L(1/4) 2 2016.03.15~
31 40230977 HOSE ASS'Y,4(7/8-14UNF)-4(7/8-14UNF) 2100L(1/2) 2
40343517 HOSE ASS'Y,4(7/8-14UNF)-4(7/8-14UNF) 2100L(1/2) 2 2016.03.15~
- 87 -
