IMBH72. BOOM CYLINDER
NO. PART NO. DESCRIPTION Q'TY I.C. SERIAL OR DATE
1 40230937 BOOM CYLINDER ASSEMBLY 1
2 40230938 ROD ASS'Y 1
3 40230859 CAP, OUTER,∅70x∅80x37L 1
4 40230766 COVER, INNER,∅70x∅40x55L 1
5 40230710 DUST, SDR,40x48x5/6.5 1
6 40230872 PACKING, U, SKY,40x50x6 1
7 40230869 PACKING, U, ISI,G55 1
8 40230861 O-RING, 1BG65 2
9 40230711 BUSHING, DU,4040 1
10 40230865 PISTION,∅70x∅27x46L 1
11 40228870 O-RING,1BG27 2
12 40230871 PACKING, U, OSI,70x60x6 2
13 40230868 BACKUP RING,70x60x3 2
14 40231139 WEARING, RYT,∅70x∅65x15L 1
15 40228864 NUT,1-14UN 1
16 40230939 TUBE ASS'Y 1
17 40231134 NIPPLE,GREASE,1/8" 1
18 40230764 SEAL KIT HEAD,NO.4~9 1
19 40230863 PISTON ASS'Y,NO.10~14 1
- 95 -
