Chapter 6 - Parameter Description [DRV]
85
☞ Note: There are WDOG error, EEP error, and ADC
Offset for the inverter Hardware Fault - the inverter will
not reset when H/W fault occurs. Repair the fault before
turning on the power.
☞ Note: Only the highest-level fault will be displayed when
multiple faults occur.
DRV-13: Motor Direction Set (7-Segment
Keypad)
This code sets the motor direction when using the 7-
Segment keypad.
7-Segment Display Description
0 Run to forward direction
1 Run to reverse direction
DRV-14: Command/Output Frequency Display
(LCD Keypad)
This code shows the Command (Target) Frequency set
in DRV00 and inverter Output Frequency.
DRV-15: Reference/Feedback Frequency Display
(LCD Keypad)
This code shows the Reference Frequency and
Feedback Frequency while PID operation.
This code appears only when ‘PID’ is selected in FU2-47.
DRV-16: Speed Unit Selection
Set this parameter to 0 [Hz] to display frequency, or to
1[Rpm] to display speed.
DRV-20: FU1 Group Selection
(7-Segment keypad)
DRV-21: FU2 Group Selection
(7-Segment keypad)
DRV-22: I/O Group Selection
(7-Segment keypad)
DRV-23: EXT Group Selection
(7-Segment keypad)
DRV-24: COM Group Selection
(7-Segment keypad)
DRV-25: APP Group Selection
(7-Segment keypad)
Select the desired group and press the PROG/ENT key
to move into the desired group. The parameter in the
group can be read and written after moving into the
desired group.
Factory Default: 0.00Hz
Related Functions: Changing the Hz/Rpm display affects the
following parameter display.
n DRV-00, 05, 06, 07, 14
n FU1-20, 21,22, 24, 25, 32
n FU2-32
n I/O-03, 05, 08, 10, 20, 21, 22, 23, 24, 42, 43
n EXT-08, 10
DRV
►
Hz/Rpm Disp
