Front View
Product Introduction
MENU: Display/exit the OSD menu.
CH+/-: Scan through channels.
VOL+/-: Adjust the volume.
EJECT: Eject the disc
PLAY: Play/pause the disc playing.
INPUT: Display the input source menu.
:Turn on/standby the TV set.
(IR) Infrared Receiver: Receives IR signals from the remote control.
(Power on/Standby) LED indicator: Press to turn on and standby.
The effective receiving range for the signal is 5-8 metres from the front of the remote
control window, and 30
0
to the left or right side and 20
0
above or below the control
window.
Indicator on(Red) Standby mode
Indicator on(Green) Power on mode
4
Remote Control window
Insert disc with label side towards back
