Ltech Super Panel 4S - Super Panel 4 S Product Introduction; Super Panel 4 S Technical Specifications

02
Input voltage
Wireless network
Working environment
Bluetooth 5.0 SIG Mesh , Wi-Fi 2.4G＋5G
-15°C~50°C , Humidity≤85%RH
Model
SP-GW-4S
Wired network
Ethernet
Dimensions
L86×W86×H41(mm)
Package size
L110×W110×H59(mm)
Display
4-inch full lamination , 480×480 resolution
Single load
Materials
PC+ V0 fireproof grade
Touchpad
Capacitive multi-touch screen , anti-fingerprint coating
Product Introduction
Technical Specs
Colors Grey , Gold , White
Inrush current in loads
Max.65A@2ms
LED≤200W , ≤400W
Channel of load
2Channels
100-240V~ , 50/60Hz
SuperPanel4S is a 4-inch smart home touchscreen control panel. It has built-in smart gateway
functions and is compatible with Bluetooth 5.0 SIG Mesh, 2.4 G+5G dual-band Wi-Fi and Ethernet
communication. SuperPanel4S can act as a 2-channel relay to directly control load lamps. With
IR capability, it is capable of controlling all your IR home appliances and turning traditional home
appliances into smart ones.
SuperPanel4S comes with a built-in 2-in-1 light and proximity sensor that enables auto screen
brightness adjustment, as well as auto screen wakeup when nearby people approach it.
It combines touchscreen and App interaction. Multi-function scenes can be set and it supports
local control without the network needed, which performs faster and more stably.
It is installed in the 86 type junction box and enables more than 400 flexible panel combinations
by using unified panel mounting frames.
