Power Up: DLP-510 363-205-401
Page 2 of 4 Issue 7, March 1997
Figure 1 – AUG11 and 40D Bank Fuse Unit
3. Remove any fuses installed in the
BFU
before inserting this unit.
4. Insert one of the
BFU
s into the appropriate
BFU( )
slot in the RT power shelf
(Table A).
FAN H 5A
ALM
AUG11
WHITE 10ACMN 5ABLUE 10AFAN L 5A
√48V
(RT)
BFU
Lucent
CMN
ALM
WHITE
ALM
FAN H BLUE
-48V
WHXBLXFAN L
40D
BFU
(RT)
Lucent
