Lucent Technologies SLC 5 Series - Page 130

363-205-401 Power Up: DLP-510
Issue 7, March 1997 Page 3 of 4
5.
NOTE:
The faceplate mounted fuses on the AUG11 may make a popping sound
when installed.
Install the correct value fuses (Table B or Table C) in fuse holders on faceplate
of
AUG11
or
40D BFU
.
Table B
AUG11 BFU Fuses
Fuse Designation Size Code
WHITE 10A WP90247 L115
CMN* 5A WP90247 L113
BLUE 10A WP90247 L115
FAN L 5A WP90247 L113
FAN H 5A WP90247 L113
* Not required in BFUs feeding a DDM-1000 or
DDM-2000 Multiplexer.
Table C
40D BFU Fuses
Fuse Designation Bead Color Size Code
WHX* Blue 3A 80C
BLX* Blue 3A 80C
CMN* Green 5A 80D
WHITE Yellow 10A 81A
BLUE Yellow 10A 81A
FAN L Green 5A 80D
FAN H Green 5A 80D
* Not required in BFUs feeding a DDM-1000 or
DDM-2000 Multiplexer.
