Lucent Technologies SLC 5 Series - Page 138

Power Up: DLP-512 363-205-401
Page 4 of 4 Issue 7, March 1997
12.
NOTE:
If voltage requirements are not met after replacement battery pack is
installed, original battery pack should be reinstalled in battery shelf.
Replace one battery pack.
13. On battery shelf, connect DMM test leads to
+BAT
jack (
J5
) and −
BAT
jack
(
J6
).
14. Does meter indicate greater than 45.0 volts DC?
If
YES,
then proceed to Step
18.
If
NO,
then continue with Step
15.
15. Have all battery packs been replaced?
If
YES,
then continue with Step
16.
If
NO,
then proceed to Step
17.
16. Check wiring and connectors on battery shelf. Repeat procedure from Step
8
after locating and correcting trouble.
17.
NOTE:
If voltage requirements are not met after replacement battery pack is
installed, original battery pack should be reinstalled in battery shelf.
Replace another battery pack and repeat from Step
13.
18. Have all equipped battery shelves been tested?
If
YES,
then proceed to Step
20.
If
NO,
then continue with Step
19.
19. Go to next battery shelf and repeat from Step
8.
20. Remove DMM. Install good fuses (15-amp) into
+BAT
and −
BAT
fuse holders
of all battery shelves equipped with batteries.
21. Insert connector
J113
into connector
P113
on battery shelf.
STOP. YOU HAVE COMPLETED THIS PROCEDURE.
