363-205-401 Power Up: DLP-513
Issue 7, March 1997 Page 3 of 8
6.
NOTE:
The four plugs supplied to upper two battery shelves (battery string 2) are
labeled
P5, P6, P7,
and
P8
.
Connect each battery lead jack to one of two plugs supplied to each shelf.
7. Get DMM and condition to measure DC volts.
8. In battery section of cabinet at power panel, refer to Table A and connect DMM
test leads to
+BAT TEST
jack
J1
or
J3
and −
BAT TEST
jack
J2
or
J4
of bat-
tery string 2.
9. Does meter indicate greater than 45.0 volts DC?
If
YES,
then proceed to Step
18.
If
NO,
then continue with Step
10.
10. Check battery lead connections at battery shelf.
11. Does meter indicate greater than 45.0 volts DC?
If
YES,
then proceed to Step
18.
If
NO,
then continue with Step
12.
12.
NOTE:
If voltage requirements are not met after replacement battery pack is
installed, original battery pack should be reinstalled in battery shelf.
Replace one of the battery packs in battery shelf.
