Lucent Technologies SLC 5 Series - Page 146

Power Up: DLP-513 363-205-401
Page 8 of 8 Issue 7, March 1997
32. On battery shelf, connect DMM test leads to
+BAT
jack (
J5
) and −
BAT
jack
(
J6
).
33. Does meter indicate greater than 45.0 volts DC?
If
YES,
then proceed to Step
37.
If
NO,
then continue with Step
34.
34. Have all battery packs been replaced?
If
YES,
then continue with Step
35.
If
NO,
then proceed to Step
36.
35. Check battery lead connections at battery shelf. Repeat procedure from Step
27
after locating and correcting trouble.
36.
NOTE:
If voltage requirements are not met after replacement battery pack is
installed, original battery pack should be reinstalled in battery shelf.
Select another battery pack on battery shelf and repeat from Step
31.
37. Remove DMM test leads.
38. Install good 25-Amp fuses (Buss ABC or equivalent) into
+BAT
and −
BAT
fuse holders on battery shelf.
39. Install good 5-Amp fuse into
HTR
fuse holder on battery shelf.
40. Insert connector
J113
into connector
P113
on battery shelf.
STOP. YOU HAVE COMPLETED THIS PROCEDURE.
