Lucent Technologies SLC 5 Series - Page 224

Power Up: DLP-533 363-205-401
Page 2 of 6 Issue 7, March 1997
3. At test connector head, verify battery fuse holders each contain a 20-Amp
fast-blow fuse.
4. Obtain one KS-21906, L4 battery.
5.
NOTE:
Under normal conditions, when the first battery is connected, the
following occurs: (a) Test set
TIME
display indicates
00 MIN: 00 SEC
; (b)
Status display indicates which test set
BATT
plug that battery is
connected to, status of the battery (
GOOD
or
REPLACE
), and the
READY
indicator lights; (c) Test set fan operates.
At test set connector head, connect battery lead to
BATT 1, 2, 3
, or
4
plug
being tested.
6.
!
CAUTION:
Damage will occur if test set is operated without fan operating.
Does test set fan operate?
If
YES,
then proceed to Step
15.
If
NO,
then continue with Step
7.
7. Connect battery lead to remaining
BATT
plugs, one at a time, and note if fan
operates.
8. Did test set fan operate for any
BATT
plug connection?
If
YES,
then proceed to Step
11.
If
NO,
then continue with Step
9.
9.
NOTE:
The test set is intended to test fully charged batteries. Before new
batteries or replacement batteries are tested, a minimum of two days
must have passed between the time the batteries are put on high rate
charge and this test is made.
Disconnect lead. Using a different battery pack, connect battery lead to any
BATT
plug.
