363-205-401 Acceptance:
Issue 7, March 1997 Page 1 of 2
DLP-500
Open RT Cabinet Enclosure
1. The cabinet is typically opened using a special key (allen-type wrench) and a
216-type tool as shown in Figure 1.
Figure 1 – Opening a Typical Cabinet with Hex Key and 216-Tool
2. On the inside of the side 1 left door there is an AC wiring diagram with a Table
for circuit breaker code. On the inside of the side 1 right door there is a label
listing the cabinet ED number and the equipage groups.
STOP. YOU HAVE COMPLETED THIS PROCEDURE.
Hex Key
216-Tool
