363-205-401 Power Up:
Issue 7, March 1997 Page 1 of 2
DLP-500
Verify Cabinet AC Power Panel Connections
1. AC power panels are typically accessed from side 1 of the cabinet. The cabi-
net is typically opened using a special key (allen-type wrench) and a 216-type
tool as shown in figure 1.
Figure 1 – Opening a Typical Cabinet With Hex Key and 216-Tool
2. On the inside of the door there is an AC wiring diagram and a Table for circuit
breaker code. See figure 2.
Hex Key
216-Tool
To Next Page
