Lucent Technologies SLC 5 Series - Page 93

Power Up: DLP-503 363-205-401
Page 6 of 10 Issue 7, March 1997
Figure 2 – Battery Shelf
24. Place batteries on battery shelf and dress battery cables as each battery pack
is placed on shelf (Figure 3).
FUSES
MOUNTING
APPARATUS
181A
CHARGER
BATTERY
337A
