Lucid ADA8824 - Section 10 ADA8824 (ADAT) Specifications

26
ADA8824 (ADAT) SPECIFICATIONS SECTION 10
Input/Output
Analog Inputs Eight, XLR-female, 20-kilohms line-level balanced bridging
Analog Outputs Eight, XLR male, 320-ohms source impedance, balanced
Digital Audio I/O AES-3 Input; Four, XLR-female
AES-3 Output: Four, XLR-male
S/PDIF I/O: Two, RCA female
Optical (ADAT): Two, TOSLINK optical
Other Digital I/O Word Clock: Two, BNC male
MIDI Input: One, DIN-5 female
MIDI Output: One, DIN-5 female
ADAT Sync Input: One, DB9 female
ADAT Sync Output: One, DB9 female
Maximum input level +25 dBu
Maximum output level +25 dBu open circuit
Performance Data Analog-to-Digital
Conversion 24-bit delta/sigma
Signal to Noise Ratio (A-weighted) > 113dBFS
THD+Noise < 0.005%, 0dBFS, 1kHz
Frequency Response 20 - 20kHz +/-0.5 dB
Dynamic Range > 113dB
Performance Data Digital-to-Analog
Conversion 24-bit delta/sigma
Signal to Noise Ratio (A-weighted) > 105dBFS
THD+Noise < 0.005%, 0dBFS, 1kHz
Frequency Response 20 - 20kHz +/-0.5 dB
Dynamic Range > 105dB
Physical
Size (hwd), in & cm 3.469 x 19 x 8.5 in (8.81 x 48.26 x 21.59 cm)
Weight, lbs & kg 14 lbs (6.36kg) net
15 lbs (6.82kg) shipping
Electrical
Power requirements 117V AC nominal, 105-125VAC 50-60 Hz, 40 watts
230V AC nominal, 205-253V AC 50 Hz, 40 watts
