Operating Instructions
Compact Weather Station
G. Lufft Mess- und
Regeltechni
k GmbH, Fe
llbach, Ger
many
83
18.6.5.5
Buffer Assignm
ent Additional Measurem
ent Comm
ands M5 / C
5: Compass
Device configured for m
easurem
ent values in metric or US u
nits
:
Measurement Value
UMB
Channel
Min
Max
Unit
Buffer ‘0’
Compass (act)
510
0.0
359.
0
°
Example: Request
with M com
mand
0M5!
00001<CR><LF>
0D0!
0+348.0<CR><LF>
Example: Request
with C com
mand
0C5!
000001<CR><LF>
0D0!
0+348.0<CR><LF>
82
84
Table of Contents
Default Chapter
3
Table of Contents
3
1 Please Read before Use
5
Symbols Used
5
Safety Instructions
5
Designated Use
5
Incorrect Use
5
Guarantee
5
Brand Names
5
2 Scope of Delivery
6
3 Order Numbers
6
Accessories
8
Spare Parts
8
Additional Documents and Software
8
4 Equipment Description
9
Air Temperature and Humidity
9
Air Pressure
9
Precipitation
9
Wet Bulb Temperature
9
Specific Enthalpy
9
Air Density
10
Wind
10
Compass
10
Heating
10
Global Radiation
10
Sensor Technology (Example: WS600-UMB)
11
5 Generation of Measurements
12
Current Measurement (Act)
12
Minimum and Maximum Values (Min and Max)
12
Average Value (Avg)
12
Vectorial Average Value (Vct)
12
6 Measurement Output
13
Air and Dewpoint Temperature
13
Wind Chill Temperature
13
Humidity
13
Air Pressure
13
Wet Bulb Temperature
14
Specific Enthalpy
14
Air Density
14
Wind Speed
15
Wind Direction
15
Wind Measurement Quality
16
Compass
16
Precipitation Quantity - Absolute
17
Precipitation Quantity - Differential
17
Precipitation Intensity
17
Precipitation Type
18
Heating Temperature
18
Global Radiation
18
7 Installation
19
Fastening
19
North Alignment
20
Selecting the Installation Location
21
8 Connections
23
Supply Voltage
23
RS485 Interface
23
Connection to ISOCON-UMB (8160.UISO)
24
Use of Surge Protection (8379.USP)
24
9 Commissioning
25
10 Configuration and Test
26
Factory Settings
26
Configuration with the UMB-Config-Tool
26
Function Test with UMB-Config-Tool
31
Operating Modes for Equipment Heating
32
11 Firmware Update
34
12 Maintenance
34
13 Technical Data
35
Measuring Range / Accuracy
36
Drawings
38
14 EC Certificate of Conformity
44
15 Fault Description
45
16 Disposal
46
Within the EC
46
Outside the EC
46
17 Repair / Corrective Maintenance
46
Technical Support
46
18 Appendix
47
Channel List Summary
47
Channel List Summary Per TLS2002 FG3
49
Communication in Binary Protocol
50
Communication in ASCII Protocol
53
Communication in Terminal Mode
55
Communication in SDI-12 Mode
58
Communication in Modbus Mode
90
19 List of Figures
98
20 Index
99
