Lufft WS501-UMB User Manual

Operating Manual Compact Weather Station
96 G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany
Reg.
No.
Reg.
Addr
Value (UMB
Channel)
Range
Scaling Factor,
signed/unsigned,
Remarks
Further Values
71
205
Absolute Humidity (act.)
Factor 10, s
73
72
225
Absolute Humidity (min.)
Factor 10, s
74
73
245
Absolute Humidity (max.)
Factor 10, s
75
74
265
Absolute Humidity (avg.)
Factor 10, s
76
75
210
Mixing Ratio (act.)
Factor 10, s
77
76
230
Mixing Ratio (min.)
Factor 10, s
78
77
250
Mixing Ratio (max.)
Factor 10, s
79
78
270
Mixing Ratio (vct.)
Factor 10, s
80
79
300
Abs. Air Pressure (act.)
Factor 10, s
81
80
320
Abs. Air Pressure (min.)
Factor 10, s
82
81
340
Abs. Air Pressure (max.)
Factor 10, s
83
82
360
Abs. Air Pressure (avg.)
Factor 10, s
84
83
405
Wind Speed km/h (act.)
Factor 10, s
85
84
425
Wind Speed km/h (min.)
Factor 10, s
86
85
445
Wind Speed km/h (max.)
Factor 10, s
87
86
465
Wind Speed km/h (avg.)
Factor 10, s
88
87
485
Wind Speed km/h (vct.)
Factor 10, s
89
88
415
Wind Speed kts (act.)
Factor 10, s
90
89
435
Wind Speed kts (min.)
Factor 10, s
91
90
455
Wind Speed kts (max.)
Factor 10 , s
92
91
475
Wind Speed kts (avg.)
Factor 10, s
93
92
495
Wind Speed kts (vct.)
Factor 10, s
94
93
406
Wind Speed fast km/h
Factor 10, s
95
94
416
Wind Speed fast kts
Factor 10, s
96
95
403
Wind Speed Std. Dev. m/s
Factor 100, s
97
96
413
Wind Speed Std. Dev. mph
Factor 100, s
98
97
503
Wind Dir. Standard Dev.
Factor 100, s
99
98
114
Wet Bulb Temp. °C (act)
Factor 10, s
100
99
119
Wet Bulb Temp. °F (act)
Factor 10, s
101
100
215
Specific Enthalpy (act)
Factor 10, s
102
101
310
Air Density (act)
Factor 1000, s
...
Reserved
125
124
Sensor Status:
Each register hoIds 4 sensor status coded with 4 bits per status. The sequence defined in
the table above is to understand as from most significant half byte to least significant half
byte. Most of the sensors have two status values, one for the sensor itself and the current
measurement value, another one for the buffer, from which average, min. And max values
are evaluated.
