Lufft WS700-UBM - Sensor Technology (Example: WS600-UMB)

Operating Manual Smart Weather Sensor
G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany 13
Figure 1: Sensor
Technology
4.15 Sensor Technology (example: WS600-UMB)
Precipitation sensor
(heated)
Wind meter
(heated)
Air temperature and relative
humidity with fan on underside
of device
Connector
Mounting bracket with
springs and self-locking nuts
Air pressure sensor in
device
Notch for attaching
connection cable
