19.2 Channel List Summary per TLS2002 FG3
The following channels are available specifically for data requests for further processing in
TLS format. These channels are only available in the UMB-Binary protocol.
DE
Type
UMB
Channel
Meaning
Format
Range
Resolution
Coding
48
1048
Result message
Air Temperature
LT
16 bit
-30 ...
+60°C
0.1°C
60.0 = 600d = 0258h
0.0 = 0d = 0000h
-0.1 = -1d = FFFFh
-30.0 = -300d = FED4h
53
1053
Result message
Precipitation
Intensity NI
16 bit
0 ... 200
mm/h
0.1 mm/h
0.0 = 0d = 0000h
200.0 = 2000d = 07D0h
54
1054
Result message
Air Pressure LD
16 bit
800...1200
hPa
1 hPa
800 = 800d = 0320h
1200 = 1200d = 04B0h
55
1055
Result message
Relative Humidity
RLF
8 bit
10% ...
100%
1% RH
10% = 10d = 0Ah
100% = 100d = 64h
56
1056
Result message
Wind Direction
WR
16 bit
0 ... 359°
1°
0° (N) = 0d = 0000h
90° (O) = 90d = 005Ah
180° (S) = 180d = 00B4h
270° (W) = 270d = 010Eh
FFFFh = not definable
57
1057
Result message
Wind Speed.
(average) WGM
16 bit
0.0 ... 60.0
m/s
0.1 m/s
0.0 = 0d = 0000h
60.0 = 600d = 0258h
64
1064
Result message
Wind Speed
(peak) WGS
16 bit
0.0 ... 60.0
m/s
0.1 m/s
0.0 = 0d = 0000h
60.0 = 600d = 0258h
66
1066
Result message
Dewpoint
Temperature TPT
16 bit
-30 ...
+60°C
0.1°C
60.0 = 600d = 0258h
0.0 = 0d = 0000h
-0.1 = -1d = FFFFh
-30.0 = -300d = FED4h
71
1071
Result message
Precipitation Type
NS
8 bit
0 = No precipitation
40 = unspecified precipitation
60 = Liquid precipitation, e.g. rain
70 = Solid precipitation, e.g. snow
Note: The channels which are actually available are dependent on the WSxxx-UMB type in
use.
The previous channels 1153 and 1253 are no longer supported. Channels 840 and 860 can
be used in their place.
