Operating Manual Smart Weather Sensor
44 G. Lufft Mess- und Regeltechnik GmbH, Fellbach, Germany
Weight including mounting bracket, excluding connection cable:
WS200-UMB
ca. 0.8 kg
WS300-UMB
ca. 1.0 kg
WS400-UMB, WS301-UMB, WS302-UMB,
WS303-UMB, WS304-UMB, WS310-UMB
ca. 1.3 kg
WS401-UMB
ca. 1.5 kg
WS500-UMB
ca. 1.2 kg
WS600-UMB, WS501-UMB, WS502-UMB,
WS503-UMB, WS504-UMB, WS700-UMB
WS510-UMB, WS800-UMB
ca. 1.5 kg
WS601-UMB
ca. 1.7 kg
Fastening: Stainless steel mast bracket for Ø 60 - 76mm
Protection class: III (SELV)
Protection type: IP66
Storage Conditions
Permissible storage temperature: -50°C ... +70°C
Permissible relative humidity: 0 ... 100% RH
Operating Conditions
Permissible operating temperature: -50°C ... +60°C
Permissible relative humidity: 0 ... 100% RH
Permissible altitude above sea level: N/A
RS485 interface, 2 wire, half-duplex
Data bits: 8 (SDI-12 mode: 7)
Stop bit: 1
Parity: No (SDI-12 mode: even, Modbus mode none or
even)
Tri-state: 2 bits after stop bit edge
Adjustable baud rates: 1200, 2400, 4800, 9600, 14400, 19200
3
, 28800, 57600
(In SDI-12 mode, the interface is changed to meet the requirements of the standard.)
Housing: Plastic (PC)
3
Factory setting; baud rate for operation with ISOCON-UMB and firmware update.
