Page 4
FEATURES
Bottom View
Top View
1/4” Tripod Mount
Low battery, Out of Level,
External Power LED
Working Mode LED
Pulse Mode LED
Pulse Mode Button
Horizontal, Vertical &
Cross Line Select Button
Plumb Up Beam Window
Vertical Beam Window
Horizontal Beam Window
Plumb Down Beam Window
Pendulum Lock & Control
Switch
