Page 9
USING THE UNIVERSAL MOUNT
The LCL4 comes with a multi-purpose universal mount that allows the unit to be attached to
multiple surfaces including wood, metal, pipes, construction tripods, camera tripods and flat
surfaces.
1/4” Tripod Mount
Use the threaded hole, located on the bottom of the universal mount, to mount the universal
mount and the attached LCL4 to a camera tripod.
5/8” Tripod Mount
Use this threaded hole, located on the bottom of the universal mount, to mount the
universal mount and the attached LCL4 to a surveyor’s tripod.
Screw / Nail Attachment Hole
Use the attachment hole to fasten the universal mount and the attached LCL4 to walls with
drywall screw of at least 2” (5cm) long.
Strap Raceways
Use the horizontal and vertical strap raceways to fasten the universal mount and the
attached LCL4 to objects such as pipes and wooden studs with a width of approximately
150mm (6”) or less
Magnets
Use the magnets, located on the back of the universal mount, to fasten the universal mount
and the attached LCL4 to objects such as steel studs. Use the magnets. Located on the
bottom of the mount, to mount the square, the universal mount and the attached LCL4 on
the floor.
Square
Square can be used as a right-angled ruler. If the LCL4 is to be used on the floor, install the
square in the universal mount to improve the stability of unit.
