12. Technical data
Because all values are subject to tolerances, there cannot be any di󰀨erences between the
data of your device and the data of the following tables!
12.1 Data of the hand and foot pumps
12.1.2 Dimensions, weight, usable quantity and ll quantity
NOTE:
The dimensions of this hydraulic pumps are exclusively dependent on the size
of the hydraulic uid tank. The types of hydraulic pumps are not outwardly
distinguishable from the outside at the pump head.
The weights, usable quantities and ll quantities of the hydraulic pumps are
exclusively dependent on the size of the hydraulic uid tank.
LH 2 / 1.8 - 50
Tank size max. operating
pressure in MPa
(1 MPa = 10 bar)
12.1.1 Pump labelling
Model series
NOTE:
The automatic pressure switch from low pressure to high pressure occurs at
2 MPa (= 20 bar)
Handpumpwithttings:
Hand pump with monocouplings:
Tank size Dimensions Weight min. required
l x w x h
(incl. max. hydraulic
uid ll level)
Fill quantity
1,8 [l]
660 x 200 x 160 [mm] 7 [kg] 2,38 [l]
25.98 x 7.87 x 6.30 [in.] 15.4 [lbs.] 0.63 [gal.-US]
3,8 [l]
676 x 200 x 160 [mm] 11,3 [kg] 4,61 [l]
26.61 x 7.87 x 6.30 [in.] 24.9 [lbs.] 1.22 [gal.-US]
Tank size Dimensions Weight min. required
l x w x h
(incl. max. hydraulic
uid ll level)
Fill quantity
1,8 [l]
761 x 200 x 160 [mm] 7,5 [kg] 2,38 [l]
29.96 x 7.87 x 6.30 [in.] 16.5 [lbs.] 0.63 [gal.-US]
3,8 [l]
777 x 200 x 160 [mm] 11,8 [kg] 4,61 [l]
30.59 x 7.87 x 6.30 [in.] 26.0 [lbs.] 1.22 [gal.-US]
