Lumantek ez-SHV+ User Manual

04. Technical Specifications
Data Input
SDI Video Input: SD/HD/3G-SDI (BNC
75Ω) x1
Video Formats:
- 720x480i@59.94/60
- 720x576i@50
- 1280x720p@50/59.94/60
- 1920x1080i@50/59.94/60
- 1920x1080p@23.94/24/25/29.97/30
- 1920x1080p@50/59.94/60
(3G-SDI Level-B not supported)
Data Output
SDI LOOP Output: SD/HD/3G-SDI (BNC
75Ω) x1
Audio Output: Stereo Jack x1
HDMI Video Output: SD/HD/3G
(HDMI Type A) x1
Video Formats:
- 720x480i@59.94 (DIP SW : 1111)
- 720x576i@50 (DIP SW : 0111)
- 1280x720p@50 (DIP SW : 1011)
- 1280x720p@59.94 (DIP SW : 0011)
- 1280x720p@60 (DIP SW : 1101)
- 1920x1080i@50 (DIP SW : 0101)
- 1920x1080i@59.94 (DIP SW : 1001)
- 1920x1080i@60 (DIP SW : 0001)
- 1920x1080p@23.98 (DIP SW : 1110)
- 1920x1080p@24 (DIP SW : 0110)
- 1920x1080p@25 (DIP SW : 1010)
- 1920x1080p@29.97 (DIP SW : 0010)
- 1920x1080p@30 (DIP SW : 1100)
- 1920x1080p@50 (DIP SW : 0100)
- 1920x1080p@59.94 (DIP SW : 1000)
- 1920x1080p@60 (DIP SW : 0000)
Connections
Power : DC Power Input (DC Jack) x1
DIP Switch : (6 Pole) x1 Video In/Out
Resolution, Video Output Ratio, LCD
Brightness
MODE : (Push Switch) x1 LCD ON/OFF,
Menu Selection
Display
2.7 inch TFT LCD : Input Video Display,
Input SDI Eye Pattern,In/Output Video
Resolution Display, Input Cable Length,
Audio Level Meter
Electrical
Power Input: DC +5V to +18V
Power Consumption: 3W(max.)
Operation Temperature: 0~45 C
Physical
Dimension: 86.3x57.2x26.6 (mm)(include
connector)
Weight: 0.3 kg(typ.)(0.66lbs)
