02. Interface
Specifications
DIP Switch
Resolution and other
settings switch
SDI IN
SDI Video
input port
SDI OUT
SDI Video loop output port
DC Input
DC Power Input
+5V to +18V
AUDIO OUT
Analog audio output port
HDMI OUT
HDMI Video output
port
MODE Switch
LCD Menu setting switch
