M310-HT Manual Introduction • 9
2 Introduction
The M310-HT is a portable blackbody calibration source utilizing a digital indicating
temperature controller that may be set to any temperature between ambient temperature to
450 °C (842 °F). A precision RTD temperature sensor is embedded in the blackbody emitter
providing high accuracy and repeatability. The temperature controller uses the industry
standard PID algorithms to control the emitter temperature to within +/- 0.1 °C. The blackbody
emitter mechanism uses a resistive heating device that provides long life, short stabilization
times and stable temperature control.
Temperature setpoints are altered simply by pressing the ↑ or ↓ arrow buttons on the controller.
The lower display is the setpoint and the upper display is the actual blackbody emitter
temperature.
2.1 CE Declaration
For information on the current CE certification, visit www.lumasenseinc.com.
2.2 Technical Data
Temperature Range:
Ambient + 5 ... 450 °C (+ 9 ... 842 °F)
Temperature Uncertainty
1
:
0.25% of reading ± 1 °C
Display Accuracy vs. NIST
Calibration:
See supplied NIST calibration report
Temperature Resolution:
0.1
°
C
Stability
2
:
0.3 °C per 8 hour period
Source Non-Uniformity:
Approximately ± 1 °C @ 250 °C or ± 2 °C @ 400 °C
Exit Port Diameter:
76 mm (3.00 in)
Heated Emitter Shape:
Flat Plate
Emissivity ε:
1.00 effective emissivity @ 8 ... 14 μm
Standard Calibration Method:
Radiometric @ 8 ... 14 μm
Temperature Sensor:
Precision platinµm RTD
Warm-up Time:
< 30 minutes ambient to 400 °C
Slew Rate to 1 °C Stability:
Approximately 6 min for a + 50 °C change
Slew Rate to 0.1 °C Stability:
Approximately 10 min for a + 50 °C change
Remote Set Point:
Via RS232
Method of Control:
Digital PID Controller
Operating Ambient Temp.:
0 ... 44 °C (30 ... 110 °F)
Cooling:
Fan cooled, air inlet on rear panel
Operating Humidity:
90% RH max, non-condensing
Power Requirements:
115 V AC ±10% 50/60 HZ 920 VA fused max., 600 W heater
(230 V AC Optional)
Dimensions (H x W x D):
207.3 mm x 280.4 mm x 266 mm (8.2” x 11” x 10.5”)
Weight:
5.6 kg (12.4 lbs)
CE Certified:
Yes
Power Requirements:
115 V AC ± 10% 50 & 60 Hz 920 VA fused max, 600 W heater
(230 V AC Optional)
1
Accuracy calibration performed radiometrically, the uncertainty of emissivity and transfer standard are
already included.
2
Provided stable AC mains voltage and minimum air flow across the exit port or emitter plate.
