‐Screwinplacethedustportfrom
underneath
‐Inserta35mmdiameterextractionhose.

‐Makesurethedustextractionisturnedon
beforetherouteris.

GuideBushFitting
‐Thedustportneedstobeinsertedto
providethe“nut”forthescrews,assembleas
shown



MountingtheChipShield
‐Simplyslotthechipshieldinoroutofits
housingonthebaseplate.


