PartsList(PR12)
No. Description No. Description
1
Screw ST4.2×16
27
Countersunk screw M4×10
2 Top cover 28
Screw M4×30
3 Speed stabilized module 29 Transparent baffle
4
Screw ST2.9×10
30
Screw M4×8
5 House 31 Base
6 Brush holder 32 Dust ejector B
7 Carbon brush 33 Dust ejector A
8 Brush holder cap 34 Hex nut M4
9 Logo plate 35 Left handle cover
10 Data plate 36
Screw ST4.2×13
11 Ruler knob 37 Speed regulator
12 Stator 38 Wire shield B
13
Screw ST3.5×13
39
Screw M5×16
14 Wind baffle 40 Spring washer 5
15 Flexible sleeve 41 Plain washer 5
16 Spring 42 Left handle
17 Guide pipe 43 Ruler locking knob
18 Locking knob 1 44 Ruler bush
19 Knob spring 45 Pipe circlip
20
Steel ball SΦ5.5
46 Twist spring
21 Spring 47 Locking screw
22
Hex socket set screw M6×16
48 Locking knob
23
Screw M6×16
49 Plain washer 4
24 Steel bush 50 Spring washer 4
25 Depth stop 51
Screw M4×10
26 Base plate 52 Ruler

