Lumberjack PR12 - Parts List (PR14)

Upper cover
Control board
24
PR14
No. Description No. Description
1
Cable
27
2
Cable jacket
28
Plastic spanner
3
Tapping screw ST4.2×16
29
Screw
4
Right handle cover
30
Spring
5
Capacitor 0.33μF
31
Washer
6
Tapping screw ST4.2×13
32
Knob spring
7
Screw M5×16
33
Knob
8
Spring washer 4
34
Left handle
9
Washer 4
35
Board B
10
Board A
36
Left handle cover
11
Right handle
37
Tapping screw ST4.2×60
12
Tapping screw ST4.2×22
38
Stator
13
Switch
39
Depth label
14
Cable clip
40
Trademark
15
Gear box
41
Housing case
16
Bearing 6003-2Z
42
Cover plate
17
Platen
43
Tapping screw ST2.9×9.5
18
Screw M4×10
44
Brush holder cover
19
Rotor
45
Carbon brush
20
Bearing 608-2Z
46
21
Still adjust
47
Brush holder bush
22
Ruler spring
48
Nameplate
23
Moving adjust
49
Wind baffle
24
Pointing piece
50
Nut
25
Ruler
51
Self lock spring
26
Screw M4×10
52
Front cover

