4
WRONG (too close)
Correct
WRONG (too far)
To cut a stake that comes to a point the blade offset has to be at 1/8”. If
the blades are set too close the tool will not cut. If the blades are set too
far the tool may cut but the stake will not have a point.
Setting the Blades
● CAUTION, keep
the blade offset
of both blades
equal (see below)
● Install and secure
the blades with
the Button Head
Cap Screws
Cardboard
Spacer
Blade Offset
● The cardboard box that the tool
comes in is about 1/8”
● Remove a piece of box to use as a
quick spacer for blade gap setting
TIP
1/8”
Max Capacity
Round 2.00” DIA
Square
