LF2020/LF2090 Sit-To-Stand Patient Lift Owner’s Manual
16
LF2020/LF2090 SIT TO ST
AND P
A
TIENT LIFT
SPECIFICA
TIONS
Note:
All dimensions giv
en in inc
hes unless otherwise specif
ied.
Base width
Open: 43"
Closed: 26"
Base height
(Clearance): 6"
Overall base length
50"
Lifting height range
Note:
As measured from sling hooks.
Minimum: 27"
Maximum: 71"
Range: 35"
Mast height
50"
W
eight capacity:
LF2020: 400 lbs.
LF2090: 600 lbs.
Rear locking caster size
4" diameter
Fr
ont caster size
4" diameter
Lifting mechanism
24
DC actuator
Batter
y
char
ger
AC 110V / 220V to DC 24V 1 amp
15
17
Table of Contents
Table of Contents
3
Introduction
4
Special Notes
4
Safety Precautions
5
Features
7
Handling Procedures
7
Assembly Instructions
8
Operating Instructions
9
Care and Maintenance
13
Maintenance Schedule
14
Troubleshooting
15
Specifications
16
Limited Warranty
17
