LUNATONE DALI - 1.4 Specification

DALI Display, Manual V1.0.6 © 2016, Lunatone Industrielle Elektronik GmbH
DALI Commands received on DALI line A are mirrored to DALI line B, this means that control devices
connected to DALI A can also control ballasts on DALI B.
Commands received on DALI B are not mirrored to DALI A, this allows to install controllers that only
affect one of the two DALI busses.
The DALI Display is a commissioning, control and input device for DALI controlled electronic ballasts.
Beside scene and group commands, algorithms for commissioning (addressing, grouping and scene
configuration) and automatic running processes (sequences, schedules and schedule lists) are
provided. Special methods like human centric lighting (circadian daylight trend) and colour control of
RGB-Dimmers is supported with the help of DALI Device Type 8 (DT8) standard.
By naming groups, scenes and automatic processes, custom backgrounds and screen saver image,
the device can be individually adapted to the application. Furthermore custom designed layouts are
offered as a manufacturer service.
The display can be controlled via the 7” touch control panel, but also via remote access through
Ethernet and hence can be operated via browser.
1.4 Specification
type DALI Display 7”
article number 86458626
Rated supply voltage mains adapter (included) 230-240VAC
Mains frequency mains adapter 50/60Hz
Rated supply voltage DALI Display 7”
24-48V DC (power supply)
or Power over Ethernet (PoE)
Power consumption 10W
Number of DALI lines 2
Current consumption of each DALI-line 2mA
Ambient temperature 0-50°C
Touchscreen size 7”
Touchscreen pixel 800 x 640
Colours 64k
Interface 2xDALI, USB, Ethernet
Dimensions L x W x H 200 x 150 x 20 mm
Type of protection IP20
Firmware (last recent version) V104
