LUNATONE DALI - 2) Group Control

DALI Display, Manual V1.0.6 © 2016, Lunatone Industrielle Elektronik GmbH
Configuration of Scene-Button (Long Press): Selection of Goto Scene, Cyclic Scene Recall, Start of
Sequences, Schedules or Schedule List. Up from V106 it is possible to start/stop the circadian
function. Due to assigning of special functions to a scene the function can be controlled from another
device that recalls the corresponding scene.
2) Group Control
Dim UP/DOWN
Send UP or DOWN
commands as long as the
button is pressed. (Only
available if the group is
ON)
Grou
p ON/OFF
Sends Recall MAX or OFF
to switch group ON / OFF
Previous Next
Page
Displayed pages can be
configured on the layout
configuration page.
OFF
Sent Broadcast or to
individual groups.
(Settings: long press
on button)
Home
This design symbolizes
that the group is OFF
Settings
Page
