Remark :
* If the impedance is lar
g
er than 10 KΩ , Rp is shown on the displa
y.
* If the impedance is less than 10 KΩ , Rs is shown on the display.
* If intend to obtain the accurate value, please test the component
into the " Pin terminals " ( 3-11, Fig. 1 ) or tested via optional
SMD tester, SMDA-22 or SMD test clip, SMDC-21.
Capacitance ( Cp/Cs ) : D 0.1≦
Range Accuracy Accuracy Remark
100 Hz/120 Hz 1000 Hz
20 pF ± ( 2% + 5d ) ± ( 1% + 5d ) After calibration
200 pF ± ( 1% + 5d ) ± ( 1% + 5d ) After calibration
2000 pF ± ( 0.8% + 5d ) ± ( 0.8% + 5d ) After calibration
20 nF ± ( 0.5% + 5d ) ± ( 0.5% + 5d )
200 nF ± ( 0.5% + 5d ) ± ( 0.5% + 5d )
2000 nF ± ( 0.5% + 5d ) ± ( 0.5% + 5d )
20 uF ± ( 0.5% + 5d ) ± ( 0.5% + 5d )
200 uF ± ( 0.5% + 5d ) ± ( 0.5% + 5d ) After calibration
2000 uF ± ( 1% + 5d ) ± ( 1% + 5d ) After calibration
20 mF ± ( 2% + 5d ) ------------------- After calibration
Range Accuracy Accuracy Remark
10 KHz 100 KHz
20 pF ± ( 1% + 5d ) ± ( 1% + 5d ) After calibration
200 pF ± ( 0.5% + 5d ) ± ( 0.5% + 5d ) After calibration
2000 pF ± ( 0.5% + 5d ) ± ( 0.5% + 5d ) After calibration
20 nF ± ( 0.5% + 5d ) ± ( 0.5% + 5d )
200 nF ± ( 0.5% + 5d ) ± ( 0.5% + 5d )
2000 nF ± ( 0.5% + 5d ) ± ( 0.5% + 5d )
20 uF ± ( 0.8% + 5d ) ± ( 0.8% + 5d )
200 uF ± ( 1% + 5d ) ------------------- After calibration
