SPECIFICATION SUBMITTAL Page
Job Name:
Job Number:
Model Numbers:
Dual Technology Switch with Occupancy Sensor
369773b 2 12.19.13
Maestro® Sensor
Specifications
Regulatory Approvals
• ULR Listed to U.S. and Canadian safety requirements
• Title 20 / 24 certified lighting control device
– Complies with Title 20 and Title 24 section 110.9
Power / Load Control
• 120 – 277 V~ 50 / 60 Hz
Key Design Features
• Dual Sensing Technology
• Switches all lighting loads
• 6 A of lighting load per circuit at 120 – 277 V~
• 4.4 A (1/6 HP) of fan load per circuit at 120 V~
• Crush/tamper resistant lens
• Smart Ambient Light Detection (ALD)
• Fixed Ambient Light Detection
• Adaptive zero-cross switching algorithm for
extended relay life (patent pending)
• XCTT Technology for minor motion and fine motion
detection
• Programmable Circuit Swapping eliminates need for
rewiring to reassign circuits after installation of a dual
circuit product. (patent pending)
Environment
• Ambient operating temperature: 32 °F to 104 °F
(0 °C to 40 °C), 0% – 90% humidity, non-condensing.
Indoor use only.
Warranty
• 5-Year Limited Warranty. For additional Warranty
information, please visit www.lutron.com/
TechnicalDocumentLibrary/Sensor_Warranty.pdf
Sensor Detection
LutronR Dual Tech sensors operate by triggering initial
occupancy using PIR technology, and maintain
occupancy using both ultrasonic and PIR technology.
Advanced Features
Switching
• Adaptive zero-cross switching—maximizes
relay life by switching at the point of minimum
energy on the AC power curve (patent pending).
Actively adapts to variations in relay timing.
XCTT Technology
Advanced sensing technology for minor motion
and fine motion detection ensures that the lights
stay on while the room is occupied, and that the
sensor does not turn on falsely when there is no
occupancy in the room. For more information,
see www.lutron.com/XCTWhitePaper
Wiring Compatibility
Model
Number
3-way with
Mechanical Switch *
Multilocation with
Accessory Switch
MS-B102-XX
MS-B102-V-XX
MS-B202-XX
* Wiring for 3-way with mechanical switch is Different than
traditional 3-way wiring. See wiring diagrams on pages 9 and 11
for instructions
Note: Dual circuit Dual Tech Occupancy sensor
switch (MS-B202-XX) is not compatible with
MaestroR accessory switches
Additional Information on Sensors
• For single-circuit PIR MaestroR Occupancy
sensor switch models, please see LutronR P/N
369666
• For MaestroR Occupancy Sensor C
•
LR Dimmer
models, please see LutronR P/N 369748
• For dual circuit PIR Maestro Occupancy sensor
switch, please see LutronR P/N 369758
• For more information, please see
www.lutron.com/occvacsensors
• Lutron Technical Hotline: 1.800.523.9466.
