SPECIFICATION SUBMITTAL Page
Job Name:
Job Number:
Model Numbers:
Dual Technology Switch with Occupancy Sensor
369773b 6 12.19.13
Maestro® Sensor
Dimensions - Single Circuit - MS-B102
Measurements shown as: in (mm).
Front View
Side View
4
11
⁄16
(119)
2
15
⁄16
(75)
1
1
⁄8
(30)
5/16 (8)
1/8 (3)
Mounting
Wallbox *
Sensor switch
Wallplate Adapter / Wallplate
(sold separately)
Mounting screws Adapter mounting screws
Operation
m30
15
5
1
Occ
Lrn
Fixd
Vac
Mode
Hi
Med
Low
Off
Hi
Med
Low
Min
PIR
PIR Sensor lens
Tap but ton
(tap on / off)
Ultrasonic
Sensitivity
Button
PIR
Sensitivity
Button
Sensor LED
(behind lens)
Pulses during
Test mode.
Timeout
Button
Sensor Mode
Button
Programming
LEDs
Ultrasonic
Transducers
* Recommended Wallbox dimensions:
3.5 in (89 mm) D X 3 in (76 mm) H X 2 in (51 mm) W
