Switch with Occupancy / Vacancy Sensor
Selection Matrix
1
XX in model number represents color/finish code.
2
Occupancy sensors can be configured as Auto-ON / Auto-OFF or Manual-ON / Auto-OFF.
Vacancy sensors are configured as Manual-ON / Auto-OFF only.
3
Standard mechanical 3-way switch cannot be combined with companion switch.
4
Companion switch MA-AS, MSC-AS, MA-AS-277, or MSC-AS-277 is required for multi-location installations (more than two locations controlling the
same lighting circuit). Up to nine companion switches may be connected.
5
BAA-compliant models.
* Note: Neutral is optional only for retrofit or replacement applications when ground connection is available. Connect green-sleeve wire
to ground when a neutral connection is not available. When a neutral connection is available, remove the green sleeve and connect the
white wire to neutral. Please note that a ground or neutral wire is required for product to function. If neither wire is present, consult a
licensed electrician.
Vacancy only
2
(Title 24 compliant)
Single-pole only
Single-pole / 3-way
capability
Works with standard mechanical 3-way switch
3
Works with companion switch
3, 4
All lighting loads (120 V~ only)
Max current rating
All lighting loads (120 – 277 V~ only)
Fan (120 V~)
Light + Fan (120 V~)
Neutral wire optional
*
Off-state power
Minimum load required
Relevant wiring diagram
Model Number
1
MS-OPS2-XX

2 A

1
MS-OPS2H-XX-C

2 A

1
MS-OPS5M-XX
 
5 A 3 A 3 A

2, 3, 5
MS-OPS5MH-XX-C
 
5 A 3 A 3 A

2, 3, 5
MS-OPS6M2-DV-XX
 
6 A 3 A 3 A

2 – 6
MS-OPS6M2U-DV-XX
 
6 A 3 A 3 A

7 – 11
UMS-OPS6M2-DV-XX
5
 
6 A 3 A 3 A

2 – 6
MS-VPS2-XX
 
2 A

1
MS-VPS5M-XX
  
5 A 3 A 3 A

2, 3, 5
MS-VPS6M2-DV-XX
  
6 A 3 A 3 A

2 – 6
MS-VPS6M2U-DV-XX
  
6 A 3 A 3 A

7 – 11
UMS-VPS6M2-DV-XX
5
  
6 A 3 A 3 A

2 – 6
4
