Lutron Electronics Maestro MS-OPS2H C Series - Mounting and Operation

Maestro Sensor
369666f 8 09.05.19
®
SPECIFICATION SUBMITTAL Page
Job Name:
Job Number:
Model Numbers:
Switch with Occupancy / Vacancy Sensor
Operation
MS-OPS2
MS-OPS5M
MS-OPS6M2-DV
MS-OPS6M2U-DV
UMS-OPS6M2-DV
MS-VPS2
MS-VPS5M
MS-VPS6M2-DV
MS-VPS6M2U-DV
UMS-VPS6M2-DV
Sensor Lens
Tapswitch
Tap on / off
Sensor LED (behind lens)
Pulses during configuration
of custom settings and in the
Test mode.
Mounting
Wallbox Occupancy sensor switch Wallplate Adapter / Wallplate
(sold separately)
Mounting screws Adapter mounting screws
Black
Blue
**
Bare
* White wire with
green sleeve
* Note: For MS-OPS6M2U-DV-XX and MS-VPS6M2U-DV-XX wire will be green wire covered by
white sleeve.
* * Note: Blue wire not on models: MS-OPS2, MS- VPS2.
