Homeowner’s Guide for the RadioRA Quick Start Package 3
®
Accessory Dimmers
Two Accessory Dimmers are included in this package
to allow for 1 or 2 multi-location installations. Some
homes do not have multi-location installations. In these
cases, the Accessory Dimmers will not be used.
Single location installation
Multi-location installation
10-Button Tabletop Master
Control (10T)
Controls RadioRA
® Dimmers remotely.
Status Indicators
(LEDs)
Glow when light
is on
ALL OFF Button
Turns all lights off
ALL ON Button
Turns all lights on
to full brightness
Using Raise/Lower Buttons on the
10T Master Control
1. Double-tap (quickly tap twice) the Master Control
button that represents the room lights or preset
lighting scene you wish to change (its LED will blink
slowly).
2. The Raise/Lower buttons will now affect only the
lights set to that button.
Note: Left column Scene buttons—LED will go out once
the scene is dimmed up or down.
Right column Room buttons—LED will turn on
once the room is dimmed up or down.
SCENE Buttons
Turn on and off
preset lighting scenes
ROOM Buttons
Monitor and turn individual room
lights on and off
Homeowner Information
Raise/Lower Buttons
Brightens/Dims all room
lights or preset lighting
scenes as a group
Double-tap
Tapswitch
• Tap on, tap off
• Tap twice quickly - lights
adjust rapidly to full
• Press and hold to activate
10-second fade to off
Dimming Rocker
• Press top to brighten
• Press bottom to dim
Service Switch
• When replacing light bulbs,
move to “OFF” position to
disconnect power
1
2
Feel free to move the Master Control to another
location. All RadioRA devices retain their
programming for over 10 years, even when they
are unplugged.
