Lutron Electronics TM-917 - Front Panel Layout; Front Panel Controls and Indicators

3. FRONT PANEL DESCRIPTION
Fig. 1
3-1 Display
3-2 Hold Button
3-3 Record Button
3-4 Recall Button
3-5 Sensor Select Button
3-6 Rel. ( Relative ) Button
3-7 Power On/Off Switch
3-8 0.10.01Button
3-9 Offset VR
3-10 CFButton
3-11 Thermocouple Socket
3-12 Pt 100 ohm Probe Socket
3-13 RS-232 Output Socket
3-14 Battery Cover/Compartment
5
