3. SPECIFICATIONS
Display LCD size : 18 mm x 45 mm.
Maximum indication 1999.
Measurement
2 ranges : Hi & Lo range
ranges & Lo range : 1999 uW/cm^2 x 1 uW/cm^2
resolution Hi range : 19990 uW/cm^2 x 10 uW/cm^2
* 1000 uW/cm^2 = 1 mW/cm^2
UV sensor Band pass 290 nm to 390 nm.
spectrum
Accuracy ± ( 4 % FS + 2 dgt ) FS : full scale
* Calibration is executed under the UVA light &
and compare with the standard UVA light meter.
* Spec. tested under the environment RF Field
Strength less than 3 V/M & frequency less than the
30 MHz only.
Sensor structure The exclusive UV photo sensor with
the cosine correction filter.
Buttons. Switch Power button, Zero button, Range switch
Sample Time Approx. 1 sec.
Over Range
indication
Weight 251 g / 0.55 LB (including battery)
Operating Temp. 0 to 50 .℃
Operating Less than 85% R.H.
Humidity
Power Supply DC 9V battery, 006P , MN 1604 (PP3)
or equivalent.
Power Approx. DC 6 mA.
Consumption
Size Main instrument : 131 x 70 x 25 mm.
Sensor probe head : 45 mm dia x 32 mm.
Sensor probe handle : 125 x 24 mm dia.
Accessories Instruction manual........... 1 PC.
Included UV sensor probe.............. 1 PC.
Optional Acc. Soft carrying case, CA-52A, CA-03.
2
