16
COMPACT DISC PLAYER D-03X
4. Optical digital input terminal (OPT)
The square optical input terminal should be used for digital
signals from a CD player or other devices equipped with a
digital output terminal using an optical digital cable.
The terminal supports the following PCM signal data.
Sampling frequency : 44.1 kHz, 48 kHz, 88.2 kHz,
96 kHz, 176.4 kHz, 192 kHz
Quantization bit rate : 16-bit, 20-bit, 24-bit
5. Coaxial digital input terminal (COAX)
The RCA digital input terminal should be used for digital in-
put signals from a CD player or other devices equipped with
digital output terminals using a coaxial digital cable.
The terminal supports the following PCM signal data.
Sampling frequency : 44.1 kHz, 48 kHz, 88.2 kHz,
96 kHz, 176.4 kHz, 192 kHz
Quantization bit rate : 16-bit, 20-bit, 24-bit
6. Optical digital output terminal (OPT)
Connect this terminal to a device such as a D/A converter or
an amplifier that has a digital input terminal using an optical
digital cable.
This terminal is a shutter-type optical terminal. Direct the
cable connector correctly when inserting the cable into the
terminal. If the cable connector is inserted forcibly in the
wrong direction, the terminal may be deformed and the
shutter may not close even after disconnecting the cable.
7. Coaxial digital output terminal (COAX)
Connect this terminal to a device such as a D/A converter or
an amplifier that has a digital input terminal using a coaxial
digital cable. However, this output will not reproduce PCM
or DSD files played into the unit from a PC or Mac.
8. Power cable terminal (AC IN)
Connect the accessory power cable here to supply power
from the AC outlet on the wall.
To Next Page
