8
COMPACT DISC PLAYER D-03X
Names and Functions
1. Operation button (OPERATION)
Toggles the power on and off.
When wiring or connection is performed, be sure to turn off
this button.
2. Operation indicator (OPERATION)
Blinks during warm-up when the operation button is turned
on and lights up when the operation state is activated af-
terward.
3. Disc tray
When inserting or removing a disc, this tray is opened or
closed by pressing the open/close button (
).
4. Open/close button ( )
Opens or closes the disc tray.
5. Remote sensor (R)
Receives signals from the accessory remote control.
6. Display window
Displays the operation status of this unit.
This display is composed of 3 indicators and display tube.
107 8 9 11 12 13 14
62 1 53 4
Front panel
To Next Page
