30
COMPACT DISC PLAYER D-03X
Digital input selection (DIGITAL IN) button
Remote control
•
Main unit
Press this button when using the unit as a
D/A converter.
1. Each time the DIGITAL IN button is
pressed, the display changes as follows.
COAXIAL → OPTICAL → USB → CD
The coaxial and optical inputs are applicable to the following
signals.
Sampling frequency : 44.1 kHz, 48 kHz, 88.2 kHz,
96 kHz, 176.4 kHz, 192 kHz
Quantization bit rate : 16-bit, 20-bit, 24-bit
The USB input is applicable to the following signals.
• PCM signal
Sampling frequency : 44.1 kHz, 48 kHz, 88.2 kHz,
96 kHz, 176.4 kHz, 192 kHz,
352.8 kHz, 384 kHz
Quantization bit rate : 16-bit, 24-bit, 32-bit
• DSD signal
Sampling frequency : 2.8 MHz, 5.6 MHz, 11.2 MHz
Quantization bit rate : 1-bit
When using Windows OS, our dedicated driver software
needs to be downloaded from the LUXMAN website and
installed.
Refer to “Driver Installation Manual” on the LUXMAN web-
site for detailed information.
When using Mac OS, this unit is automatically recognized.
Caution:
Connection between a PC and this unit using a USB cable
should not be performed before the installation of the dedicat-
ed driver software is completed. Failure to observe this may
cause malfunction.
• Each time the DIGITAL IN button on the main unit is held
down, the output can be toggled on and off. Each time
the button is held down, the output can be toggled on
and off.
• Even if the DIGITAL IN button on the remote control is
held down, the digital output cannot be toggled on and
off.
2. The selected input type and sampling
status are displayed on the main unit
display window.
This sampling frequency and bit count of the digital signal
are displayed, which is connected to the input terminal
(COAX/OPT/USB) selected with the digital input selector.
When one of COAX/OPTICAL/USB is selected using the
digital input selector and the digital signal from each digi-
tal device and this unit are synchronized, the sampling fre-
quency and bit count of the digital signal are displayed.
When a digital signal input is not provided or the signal is not
synchronized even if the signal input is provided, “UNLOCK”
is displayed.
When USB is selected, only the sampling frequency is dis-
played. The bit count is not displayed.
• The bit count (word length) indicates the contents of the
word length data included in the channel status which is
specified in IEC60958-3 (digital audio interface - Part 3:
consumer applications).
Some output devices may provide channel status data
(word length data) whose content is different from the
actual word length. In such a case, the contents of the
channel status data are indicated on the display instead
of the actual bit count.
Alternatively, some devices or sources may provide
the data that states “the word length is not specified”.
In such a case, the bit count is not displayed.
• There may be a case where the display indicates “LOCK”
shortly, and then “UNLOCK”. (The reverse case is also
possible.) That is because the former state (LOCK/
UNLOCK) is indicated for approx. 0.5 seconds since an
input signal is changed until the circuit gets stable.
To Next Page
