SUPER AUDIO CD PLAYER D-07X
6. USB digital input terminal (USB)
Use this USB (B-type) input terminal digital input signals
from a PC or Mac using a USB cable. The terminal supports
the following signals.
• PCM signal
Sampling frequency: 44.1 kHz, 48 kHz, 88.2 kHz,
96 kHz, 176.4 kHz, 192 kHz,
352.8 kHz, 384 kHz,
705.6 kHz, 768 kHz
Quantization bit rate: 16-bit, 24-bit, 32-bit
• DSD signal
Sampling frequency: 2.8 MHz, 5.6 MHz,
11.2 MHz, 22.4 MHz
Quantization bit rate: 1-bit
Before connecting this unit to a PC or Mac the dedicated
driver software needs to be downloaded from LUXMAN
website and installed.
Refer to “Driver Installation Manual” on the LUXMAN website
for detailed information.
Caution:
Connection between a PC
or Mac and this unit using a USB
cable should not be performed before the installation of the
dedicated driver software is completed. Failure to observe this
may cause a malfunction.
7. Optical digital input terminal (OPT)
When using this unit as a D/A converter, transmit digital
signals from a CD player or the like that has a digital output
terminal to this unit using an optical digital cable.
The terminal supports the following PCM signals.
Sampling frequency: 44.1 kHz, 48 kHz, 88.2 kHz,
96 kHz, 176.4 kHz, 192 kHz
Quantization bit rate: 16-bit, 20-bit, 24-bit
This is a shutter-type optical terminal. Direct the cable
connector correctly when inserting the cable into the terminal.
If the cable connector is inserted forcibly in the wrong
direction, the terminal may be deformed and the shutter may
not be able to close even after disconnecting the cable.
8. Coaxial digital input terminal (COAX)
When using this unit as a D/A converter, connect a CD
player or the like that has a digital output terminal to this unit
using a coaxial digital cable.
The terminal supports the following PCM signals.
Sampling frequency: 44.1 kHz, 48 kHz, 88.2 kHz,
96 kHz, 176.4 kHz, 192 kHz
Quantization bit rate: 16-bit, 20-bit, 24-bit
9. Optical digital output terminal (OPT)
Connect this terminal to a device such as a D/A converter or
an amplifier that has a digital input terminal using an optical
digital cable. When a Super Audio CD (HD layer selected)
or a DSD file is played back, a digital audio output cannot
be not provided. In addition, when PCM data of 352.8kHz,
384 kHz, 705.6 kHz or 768 kHz sampling frequency is
played back, digital audio output is not available.
This is a shutter-type optical terminal. Direct the cable
connector correctly when inserting the cable into the terminal.
If the cable connector is inserted forcibly in the wrong
direction, the terminal may be deformed and the shutter
may not be able to close even after disconnecting the cable.
10. Coaxial digital output terminal (COAX)
This terminal is connected to an amplifier that has a digital
input terminal using a coaxial digital cable. When a Super
Audio CD (HD layer selected) or a DSD file is played back, a
digital audio output cannot be not provided.
In addition, when PCM data of 352.8 kHz, 384 kHz,
705.6kHz or 768 kHz sampling frequency is played back,
digital audio output is not available.
11. Main power switch (MAIN POWER)
Turns this unit to the standby state. When this switch is set
to ON/STANDBY, the standby indicator on the front panel
lights up to show that this unit turns to the standby state.
When this switch is set to OFF, the standby indicator on the
front panel turns off to show that the main power is turned
off.
12. Power cable terminal (AC IN)
Connect the accessory power cable here to supply power
from the AC outlet on the wall.
