22
SUPER AUDIO CD PLAYER D-07X
How to connect output devices
1. Unbalanced connection with a device
such as an integrated amplifier
(Refer to connection diagram (D).)
Connect between the analog unbalanced output terminals
(LINE) of this unit and the unbalanced input terminals of a
device such as an integrated amplifier with 2 (L/R) RCA-
plug cables.
2. Balanced connection with a device
such as a pre-amplifier
(Refer to connection diagram (E).)
Connect between the balanced analog output terminals
(BAL LINE) of this unit and the balanced input terminals of
a device such as an integrated amplifier with two balanced
XLR cables (L/R).
3. Digital output to a device such as
another D/A converter
(Refer to connection diagram (F).)
Connect between the digital output terminal (COAX/OPT)
of this unit and a device such as a D/A converter or a unit
equipped with digital input terminals with a coaxial digital
cable or an optical digital cable.
How to connect between the trigger input
terminal and other devices
Use a commercially available 3.5 mm monaural mini-plug
cable to connect to a device with a trigger output terminal.
This connection enables this unit to turn to operation/standby
in conjunction with the connected device.
When connection is conducted from a product made by
other than LUXMAN, make sure that the trigger output is
12 V. The trigger input of this unit should be 12 volts, the
current consumption is 13 mA.
To Next Page
