10



Whenchoosingalocationforthelightingtower,bearinmindthefollowing:

‐ Assesssiteconditionscarefullybeforepositioningandoperatingthemachine.

‐ Theworking area should berelativelyleveland solid. Thiswill ensuresmooth, trouble‐freetelescopingofthe mast.

(whichmaynottelescopeproperlyifthe

unitisnotlevel.)

‐ Donotpositionthetowerinthevicinityofoverheadcablesorpowerlines!

‐ Neverraisethemastoroperatethetowerwithoutproperlyjackingtheunit!

‐ Formaximumlightcoverageandilluminationefficiency,locatetheunitatgroundlevelorina

spothigherthanthearea

beingilluminatedbythelamps.

‐ Donotmovethetowerwiththemastraised!



Stabilizingtheunitasfollows:

 Holdthestabilizerwithonehandandpullthelockingpintoreleaseit.Pullthestabilizeroutwardandrestingitonthe

ground.(pictureA)

 Securethetensioner(1)tothepin(2).

 Adjustthestabilizersextensionkeepingthepin(3)

raisedandpullingoutthepart(4)

 Turnthetensioneradjustmentuntilall3stabilizerstouchtheground.

 Fixtheunitfirmlytotheground,usingtheindicatedholes(5).





LIGHTINGTOWERUSE

LIGHTING



TOWER



POSITIONING



STABILIZING



THE



UNIT


