Luxtower LUX S10 - Technical Data

8


FLOODLIGHTS
Type LED
Power(each) 50W
Floodlightinstalled 6
IPlevel 65
Totallumen 39000
Illuminatedarea 1900sqm
Operatingtemperaturerange ‐30Ԩ~45Ԩ
Voltage 230V
Frequency 50Hz
MAST
Liftingmethod Pneumatic
MaximumHeight 4,3m
MaximumWindSpeed 110km/h
Rotation 360°
GENERAL
Weight 83kg

DIMENSIONS

 
1450 mm
2372 mm
2058 mm
440 mm
404 mm
5
2
0
m
m
TECHNICALSPECIFICATIONS
TECHNICAL

DATA

