Luxtower LUX S10 - Adjust the Mast Height; Lower the Mast

12


 Openthefirstknob,whichallowsyoutofreeupthemovementofthefirstsectionofmast.
 Liftingthefirstsectioncompletely,actingonthehandpump.
Asectioncompletelyraised,proceedtolockitthroughthehandwheel,butonlyafterhavingstoppedtheairinletinthe

mast.
 Loosenthesecondhandwheelandrepeatthepumpingoperationandthenlockinguponcompletionoflifting.
 Repeattheoperationuntilyoureachthedesiredheightorthecompleteextensionofthecolumn.





 Proceedtotheloweringofonesectionatatime,startingfromthelastonethatwasraised.
 Thenloosenthelowerhandwheel,actonthevalvetodischargetheaircontainedinthemast.
 Proceedasyougowiththenexthandwheeluntiltheoperationiscomplete.

 Lockallthehandwheels

ATTENTION!
Incaseof particularly rigidtemper atures,difficultiescanoccur in thecompleteloweringofthecolumn forinternalice
formation;Normallytheweightmountedonthetopofthecolumnissufficienttoremovethepossiblepresenceofice.
Otherwiseusesimpledenaturedethyl
alcoholintheareaoftheterminal ringsattheendofeach singleextension;ifthe
icepersists,useaheater(max50°)inordertoremovethethickericesheetth atpreventstheclosingoftheextensions
andsubsequentlyprovideforthedischargeofthewaterintroduced
intheformofcondensationofmoisturepresentin
theairoffilling.
Thispracticemusthoweverbeadoptedonaweeklybasis.Thelimitofuseissetattemperaturesbelow‐40°C.





LIGHTINGTOWERUSE
ADJUST

THE

MAST

HEIGHT

LOWER

THE

MAST

Opening
rotation
Manualpump
Condensationwater
exhaustValve
