Angle of bank is indicated by the position of the pointer on the bank scale.
Turn coordinator
Figure 53. Turn coordinator widget
Standard rate turn indicator - standard rate turn indicator is represented by two airplane
silhouettes on the bank indicator. The silhouettes are hidden when IAS is less than 10 m/s.
The pilot performs standard rate turn when the bank indicator marker (yellow triangle) aligns
with airplane silhouette.
The standard rate turn is defined as 3° per second turn (which gives a complete 360° turn in 2
minutes).
Bank pointer - bank pointer is displayed as a yellow triangle and is always fixed at its position.
Underneath the yellow triangle we can find Slip/skid indicator.
Slip/skid indicator is displayed as a thin rectangle below the Bank pointer. The combination of
the two is also referred to as ”sailboat” due to its looks.
